This document addresses the generic root-mean-square (RMS) simulation models of inverterbasedgenerators for power system dynamic analysis. The scope of the document covers the grid-connected IBGs for photovoltaic power generation systems, wind turbine generation systems with full-scale converters (i.e. Type-4 wind turbine systems), wave energy generation systems, fuel cell energy generation systems, battery energy storage systems, supercapacitor energy storage systems, flywheel energy storage systems, AC- or DC-coupled hybrid energy generation or storage systems, etc.

Given the technical commonalities of full inverter-based generation systems in dynamic characteristics and grid specification requirements, this document is technically backward compatible with the specification of IEC 61400-27-1 [1]1 (particularly compatible with the Type-4A wind turbine model specification). Additionally, several feature-rich modules have been added to provide fast frequency response, negative sequence control under unbalanced grid conditions, voltage source interface to improve numerical stability under weak grid connection conditions, etc. Generic model specifications for Type-3 wind turbine systems are out of scope and can be found in IEC 61400-27-1 [1]. The aggregated model for a renewable energy power plant and the plant-level control are also out of scope. The models specified in this document can be primarily used for power system RMS dynamic simulation analysis in the electromechanical time scale. The validation specification for the models in this document will be developed exclusively in a new document, which will align with the procedures, requirements, and methodologies already specified in IEC 61400-27-2 for wind turbine models [2].
