ISO 5210:2026 Industrial valves - Multi-turn actuator attachments
standard byInternational Organization for Standardization , 02/01/2026

More info

This document specifies the requirements for the attachment of multi-turn actuators to valves.

u000b

Throughout this document, “actuator” can be understood as “actuator” or “combination of actuator with gearbox” providing a multi-turn or linear output.

u000b

This document specifies:

u000bu000bflange dimensions necessary for the attachment of actuators to industrial valves [see Figure1a)] or to intermediate supports [see Figure1b)];u000bthose driving component dimensions of actuators which are necessary to attach them to the driven components;u000breference values for torque and thrust for flanges having the dimensions specified in this document.u000b
