This document specifies the characteristics of hexalobular socket button head screws with reduced loadability due to head design, in steel and stainless steel, with metric coarse pitch threads M3 to M12, and with product grade A.

If, in certain cases, other specifications are requested, property classes and stainless steel grades can be selected from ISO 898-1 or ISO3506-1, and the dimensional options from ISO888 or ISO4753.

NOTE The reduced loadability (related to the head dimensions in combination with penetration of the hexalobular socket specified in this document) implies a limitation of ultimate tensile load shown by a specific marking (property class preceded by a zero). The loadability in the head is assumed to be 80% of that in the thread for all sizes and all property classes, see Table4.
