This document focuses on recommending condition monitoring (CM) techniques for detecting and diagnosing developing machine faults associated with the most common potential failure modes in reciprocating compressors.

u000b

This document is intended

u000bu000bto set out a reliable and effective CM approach for reciprocating compressors,u000bto create a mutual understanding of the criteria for successful reciprocating compressor CM and to foster cooperation between the various application stakeholders,u000bfor use by end-users, contractors, consultants, service providers, machine and part manufacturers and instrument suppliers,u000bas the reciprocating compressor design, its operation and maintenance regime can be very different from one application to the next, it is important to highlight that condition monitoring and diagnostics method described in this document is reference guidelines and non-mandatory information, andu000bTo make this standard more effective, it is required to actively share the operation and condition data of the reciprocating compressor among the relevant parties.u000bSome of the reciprocating compressor types covered by the requirements of this document include:u000bslow (under 600r/min) and moderate speed (600r/min to 1000r/min) machines manufactured and procured in accordance with the requirements of API STD 618;u000bhigh-speed and pre-packaged machines (over 1000r/min) on a skid that are manufactured and procured in accordance with the requirements of ISO 13631 or API SPEC 11P;u000bhyper compressors used for secondary ethylene compression in low density polyethylene (LDPE) production;u000blubricated and non-lubricated machines;u000bwater-cooled and gas-cooled machines;u000bhorizontal, vertical V-type, L-type and W-type machines;u000bhorizontal, vertical machines with piston rings and those with labyrinth seal pistons (vertical machines only);u000bsingle-acting and double acting machines;u000bmachines with a tandem cylinder configuration;u000bsingle and multi-stage compression machines;u000bmachines with and without capacity control;u000bring, poppet, reed and plate valve type machines;u000bmachines mounted on flexible and rigid structures;u000bmachines driven by electric motors, gas and diesel engines, turbines (with or without a gearbox) all with a flexible or rigid coupling;u000btintegral gas-engine-driven machines (engine portion out of scope);u000boffshore applications (e.g. platforms, FPSOs (floating production storage and offloading), FLNGs (floating liquified natural gas), FPU (offshore foating production unit) and fixed installations).u000bu000b

This document focuses on the compressor itself (cylinders, distance pieces, crosshead, frame and all internal parts) and not on the prime mover or the external systems (e.g. piping, scrubbers, pulsation vessels, and pulsation control devices). Only brief mention is made of monitoring the foundation, skid and pedestal.

u000b

The scope does not include requirements for monitoring the auxiliary systems (e.g. for lubrication, cylinder cooling, intercoolers and gas purging), but process parameters from these systems are often monitored.

u000b

The scope does not cover installation analyses of systems either, (e.g. pulsation and mechanical response and thermal analysis of the piping).

u000b

This document covers online (permanently installed) and portable instrument CM and diagnostic techniques for operating reciprocating compressors.

u000b

Machine testing, which is only done during shutdown, although very important, is not part of the scope of this document, nor is the one-time acceptance and performance testing.

Product Details

Published:

03/01/2026

File Size:

1 file , 6.8 MB

Note:

This product is restricted and cannot be purchased in the following countries Ukraine, Russia, Belarus
